Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated

Certification
China Qingdao KaFa Fabrication Co., Ltd. certification
China Qingdao KaFa Fabrication Co., Ltd. certification
Customer Reviews
KAFA is a professional steel fabricator,The quality could match Aus standard. Good service.

—— Jonathon Dunlop

KAFA's engineer team is very great. Economical design and cost-effective plan helps us save much money. Thank you KAFA team!

—— Stephane

We cooperated with KAFA for more than 4 years, Good price, high quality, and most important is the on time delivery time. Especially the shop drawings drafting service, They can use Chinese material instead of Australian material properly.

—— James

I'm Online Chat Now

Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated

Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated
Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated

Large Image :  Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated

Product Details:
Place of Origin: Qingdao, China
Brand Name: KAFA
Certification: ISO BV
Model Number: Panel 01
Payment & Shipping Terms:
Minimum Order Quantity: 1000sqms
Price: Negotiate
Packaging Details: In bundle
Delivery Time: 5-8days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000/week

Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated

Description
Material: PPGI +foam + PPGI Thickness: 50 75 100 150 200mm
Width: 900mm - 1200mm Density: 8~20KG/M3
Color: Red, Sea Blue, White Grey, Etc. Core Material: Polyurethane Foam
Application: Wall/roof/partition Length: 1-11.8M
High Light:

lightweight steel frame construction

,

prefabricated steel construction

Customized Size Fireproof corrugated PU/PIR/Glasswool sandwich panel Zinc Coated Sandwich Panel

Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated 0Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated 1

Advantages

Polystyrene EPS /PU sandwich panel Advantages

1. Light weight: 8-20kg/m3, easy to install(donnot need crane), save more construction period and reduce the cost.
2. Excelent Sound Insulation, heat insulation, waterproof and damp resistant with the good appearance.
3. Large load: Used as supporting structure and defense device for it's characteristic of high intension rigidity.
4. Panel length is based on the buyer's request, and the steel color is flexible based on the RAL standard, that makes your building more beautiful.
5. Eco-friendly



Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated 2

Product Name
Heat insulation pu panels/sip polyurethane panel sandwich for prefab house
Application
Roofing,Wall,Prefab House,Cold Room,Warehouse,Workshop
Advantage
Light Weight&Easy to install
Material
Color Steel Sheet&Polyurethane
Temperature Range
-40~200
Thickness
50/75/100/150/200mm
Length
1-11.8m
Life time
30 years

Technical parameter
Effective width
900-1150mm
Thickness
50-200mm
Length
According to customer's request panel
Materials
Polystyrene foam, Color steel sheet
Structure
Upper and lower layer: Color steel sheet panel
Character
Light in weight, heat insulation, water resistant, green and environmental sandwich panel
Use
Various roofs and walls referring to the large size factory buildings, storages, exhibit



Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated 3
EPS flame retardant sandwich panel:
As economical EPS composite boards, they are characterized by light weight, good
heat and noise insulation, great water tightness and long service life.
Technical function Unit Index Qualification
Fibre average
diameter
μ m 4-7 GB/T13350-92
Density kg / m 3 7-18 GB/T13350-92
Heat conductivity w/m.k 0.030-0.04 GB/T13350-92
Incombustibility grade B1 GB/T13350-92
Hydrophobic nature % > 98 JISA9512-79
Use temperature °C -268-200
Moisture rate % < 5
Specification
Photos:
Effective width Wall panel: 950mm 1150mm 1200mm Roof panel: 970mm 980mm
Length According to customer' s request
materials Polystyrene foam board(EPS), Color steel sheet,
Structure
Upper and lower layer: Color steel sheet
Middle: polystyrene foam board
Thickness Color steel sheet: 0.3-0.6mm
Polystyrene foam board: 50mm 75mm 100mm 150mm 200mm
density ,EPS 8kg/m3 flame retardant
Conventional
color Ocean blue, tephrosious
lifetime 15~20 years
Character Light in weight, heat insulation, water resistant, green and environmental
Use various roofs and walls referring to the large size factory buildings, storages,
exhibition halls, gymnasiums etc.

Product Line
Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated 4
Packing & Delivery
Customized Size Fireproof Insulated Sandwich Panels Corrugated Zinc Coated 5
