Product Details:
|
| Material: | Welded H Beam | Surface Treatment: | Alkyd Primer, DFT 80um |
|---|---|---|---|
| Structure: | Portal Structure Frame | Wall: | EPS 50MM |
| Roof: | EPS 50MM | Downpipe: | 110mm Diameter, PVC |
| Life Time: | 50 Years | Dimension: | 80*60M*80(Length*width*eave Height) |
| Door: | Sliding Door | Window: | PVC |
| Cannopy: | Frame+double Sheet, 3.2m Length | Brick Wall: | 1.2m Height |
| High Light: | EPS Roof Steel Structure Warehouse,H Section Steel Structure Warehouse,anti wind Steel Structure Warehouse |
||
H Section Anti Wind EPS Roof Steel Structure Warehouse
Professionally designed prefab steel structure warehouse building
1. Sturdy steel structure frame, firm, windproof, snowproof and earthquake resistant.
2. Plastic steel is easy to design as a steel warehouse material. Therefore, the warehouse has large space and light weight.
3. The color sandwich panel and color corrugated steel plate are used as the maintenance system, which has the functions of heat insulation, beauty, waterproof and sound insulation.
4. The bolted steel workshop is easy to install and disassemble.
5. Cold-formed steel sinks and downpipes are very suitable for drainage systems.
>> Main parts of the steel structures and technical parameters:
| Main Steel Frame System | |
| Main structure | H section steel Q345, alkyd painting, two primary painting, two finish painting |
| Roof purlin | XZ160*60*20*2.5, galvanized |
| Wall purlin | XZ160*60*20*2.5, galvanized |
| Intensive bolt | Grade 10.9 |
| Turn buckle bolt | M20+2, steel Q235, processing |
| Anchor bolt | M24, steel Q235, processing |
| Ordinary bolt | Galvanized bolt M20 |
| Ordinary bolt | Galvanized bolt M12 |
| Brace nut | Galvanized bolt M12 |
| Bracing System | |
| Cross brace | Φ20 round steel bar Q235, process and painted (alkyd painting) |
| Angle brace | L50*5 angle steel Q235, process and painted (alkyd painting) |
| Column bracing | Φ25 round steel bar Q235, process and painted (alkyd painting) |
| Tie bar | Φ127*3 steel pipe Q235, process and painted (alkyd painting) |
| Batter brace | Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting) |
| Wall & Roof System | |
| Roof panel | Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU) |
| Wall panel | Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU) |
| Edge cover | 0.4mm color plate, angle Alu. |
| Fittings & accessories | Nails, glue etc. |
| Unpowered ventilator | Diameter Φ600, stainless steel |
| Sky lighting band | 1.2mm FRP, double layer |
| Sliding door | sandwich panel door |
| Roof drainage system | |
| Gutter | 0.8mm color steel plate |
| Rainspout pipes | Φ160 PVC pipe |
Benefit:
#Environmental protection: All materials in the steel warehouse are made of steel and can be reused many times.
#Beautiful appearance: The warehouses with colored steel plate wall panels and roof panels are beautiful and clean.
#Quality: The steel structure warehouse with steel structure frame and color steel plate panel is very strong.
#Good drainage system with cold-formed steel gutter and pvc downpipe
#Connection: All steel materials are connected with high-strength bolts, shear bolts, bracket bolts, etc., which are easy to install and disassemble.
# Delivery time is short. All materials are packed in containers and then shipped abroad.
# Short production time: The warehouse with flexible design is divided into many steel structure parts, manufactured by skilled workers in advanced machines.
# Installation: If necessary, our engineers will provide technical guidance on site.
