Portal Sliding Frame Durable Q235 Steel Structure Warehouse

Portal Sliding Frame Durable  Q235 Steel Structure Warehouse
Portal Sliding Frame Durable  Q235 Steel Structure Warehouse Portal Sliding Frame Durable  Q235 Steel Structure Warehouse Portal Sliding Frame Durable  Q235 Steel Structure Warehouse

Large Image :  Portal Sliding Frame Durable Q235 Steel Structure Warehouse

Product Details:
Place of Origin: Qingdao, China
Brand Name: KAFAFAB
Certification: ISO 9001
Model Number: Steel structure warehouse
Payment & Shipping Terms:
Minimum Order Quantity: 1000 square meter
Price: USD 45~60/sqm
Packaging Details: Nude pack or steel pallet
Delivery Time: 40 days after deposit and shop drawing confirmed
Payment Terms: L/C, T/T
Supply Ability: 20000 square meter per Month

Portal Sliding Frame Durable Q235 Steel Structure Warehouse

Description
Material: Welded H Beam Surface Treatment: Alkyd Primer, DFT 80um
Structure: Portal Structure Frame Wall: EPS 50MM
Roof: EPS 50MM Downpipe: 110mm Diameter, PVC
Life Time: 50 Years Dimension: 80*60M*80(Length*width*eave Height)
Door: Sliding Door Window: PVC
Cannopy: Frame+double Sheet, 3.2m Length Brick Wall: 1.2m Height
High Light:

Q235 Steel Structure Warehouse

,

Portal Sliding Steel Structure Warehouse

,

80M Steel Structure Warehouse

Large span steel structure building for warehouse



The reason why steel structure houses are becoming more and more popular?


1. Light weight, resistant to earthquakes and strong winds Strong resistance
2. Low maintenance costs and high material quality, such as galvanized steel, which reduces sustainability and life cycle costs
3. Modular and error-free prefabrication shortens the construction period of building components
4. Realize environmental friendliness due to reusable steel parts and reduce waste by effectively using materials in the factory
5. Repositionable, replaceable and load-bearing walls provide functions and effectively use space



>> Main parts of the steel structures and technical parameters:



Main Steel Frame System
Main structure H section steel Q345, alkyd painting, two primary painting, two finish painting
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Intensive bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt M24, steel Q235, processing
Ordinary bolt Galvanized bolt M20
Ordinary bolt Galvanized bolt M12
Brace nut Galvanized bolt M12
Bracing System
Cross brace Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing Φ25 round steel bar Q235, process and painted (alkyd painting)
Tie bar Φ127*3 steel pipe Q235, process and painted (alkyd painting)
Batter brace Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)
Wall & Roof System
Roof panel Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Wall panel Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Edge cover 0.4mm color plate, angle Alu.
Fittings & accessories Nails, glue etc.
Unpowered ventilator Diameter Φ600, stainless steel
Sky lighting band 1.2mm FRP, double layer
Sliding door sandwich panel door
Roof drainage system
Gutter 0.8mm color steel plate
Rainspout pipes Φ160 PVC pipe




Application field



Steel structure buildings are widely used in the construction of buildings, such as warehouses, workshops,

And large factories. Hangar/garage/chicken shed, exhibition hall, agricultural warehouse, logistics center, etc.



Product features



1. Low maintenance cost

2. Environmental protection and recyclable.

3. Flexibility when fixing doors, windows and indoor partitions

4. The steel structure is firm, durable and stable.

5. Steel parts are resistant to termites and other destructive insects.

6. The service life exceeds 50 years

7. Fast construction speed, convenient installation and convenient transportation.



Price



Basic design requirements: design load (very important)

1. Snow load:

2. Wind load:

3. Earthquake magnitude:

4. Is the middle column allowed:

5. Project location:

6. Length (side wall, m):

7. Width (end wall, m):

8. Wall height (eaves, meters):

9. Is it mezzanine? And usage:



Building use:



A. Warehouse/Storage

B. Factory

C. Agricultural Barn

D. Retail Store

E. Maintenance/mechanical workshop

F. Office space

G. Animal farm (please confirm which animal)
