Prefab Steel Structure Commodity Storage Warehouse Construction Solution

Prefab Steel Structure Commodity Storage Warehouse Construction Solution
Prefab Steel Structure Commodity Storage Warehouse Construction Solution
Prefab Steel Structure Commodity Storage Warehouse Construction Solution Prefab Steel Structure Commodity Storage Warehouse Construction Solution Prefab Steel Structure Commodity Storage Warehouse Construction Solution Prefab Steel Structure Commodity Storage Warehouse Construction Solution

Large Image :  Prefab Steel Structure Commodity Storage Warehouse Construction Solution

Product Details:
Place of Origin: Shandong, China
Brand Name: KAFA
Certification: ISO 9001:2015; ISO14001:2015; ISO45001:2018
Model Number: KAFA-2023022
Payment & Shipping Terms:
Minimum Order Quantity: 1000 square meter
Price: USD40~60 per square meter
Packaging Details: In nude or packed on steel pallet and loaded into 40' HQ/OT
Delivery Time: 6 weeks after shop drawing approval
Payment Terms: T/T, L/C
Supply Ability: 15,000 square meter per month

Prefab Steel Structure Commodity Storage Warehouse Construction Solution

Description
Application: Steel Workshop Type: Light,Heavy,steel Structure
Standard: GB Standard Material: Q355B/Q235B, Steel
Purlin: C/Z Section Galvanized Steel(Q235) Surface Treatment: Hot Dip Galvanised,two Primer And One Top Paint, DFT 70μm
Door: Sliding Door/Rolling Door/Swing Door Window: Aluminum Alloy Or Plastic Steel
Drawing Design: AutoCAD,PKPM,Tekla Structure Service Life: 50 Years
High Light:

Steel Structure Commodity Storage Warehouse

,

Steel Commodity Storage Warehouse

,

Prefab Steel Commodity Storage Warehouse


Prefab Steel Structure Commodity Storage Warehouse Construction Solution

The Prefab Steel Structure Commodity Storage Warehouse Construction Solution is a building structure made of steel, including internal support and external enclosure structure. The steel frame is made of a portal steel frame, including steel columns, steel beams, and bracing. The portal steel frame and the external enclosure structure constitute an enclosed building structure with sufficient strength to withstand severe weather such as strong wind, rain, and snow.

Metal structures processed the cut, welded, drilled, and painted in the workshop, and then transported to the construction site, often referred to as prefabricated structures. The prefabricated steel structure does not need to be welded on-site, and each component only need to be fixed with bolts, which is convenient and quick to install and save labor. Five main types of structural components make up the steel frame-tension members, compression members, bending members, combined stress members, and their connections.



Technical parameters:



Dimension

Length x width x Eave height, roof slope

Type

Single slope, double slope, muti-slope;
Single span, double-span , multi-spans;
Single floor, double floors , multi-floors

Foundation

Concrete and steel foundation bolts

Column and beam

Hot rolled or welded H steel Q355, all bolts connection, straight cross-section or Variable cross-section

Bracing

X or V or other type bracing made from angle steel or steel bar

C or Z purlin

C/Z section steel with size C160-300 or Z160-300

Roof and wall panel

Single colorful corrugated steel sheet;
sandwich panel with insulation of EPS, Rock wool, glass wool or PU

Accessories

Semi-transparent skylight belts, Ventilators, down pipe, gutter,doors,windows, etc

Surface treatment

Painting or hot dip galvanized

Package

Nude or packed on steel pallet and then loaded into 40'HQ/OT



Wall and roof system:

The roof panel is usually a single continuous length from the eaves to the ridge line for portal frame buildings.
Wall panels are usually the continuous length from the bottom wall to the eaves of the building.It is usually a corrugated single-color metal sheet with a thickness of 0.4mm-0.6mm. For a factory building that requires thermal insulation, you can choose to use a sandwich panel.

Prefab Steel Structure Commodity Storage Warehouse Construction Solution 0    Prefab Steel Structure Commodity Storage Warehouse Construction Solution 1



Advantages of Commodity storage warehouse built with Prefabricated steel frame Structure construction:



1. Construction period

In terms of the construction period, the steel structure has obvious advantages. The prefabricated steel structure building  is speedy because its construction is produced in the factory on the construction site. Only hoisting and splicing can meet some manufacturers’ needs for emergency construction and warehouse construction.



2. Environmental protection
After the steel components are processed and transported to the construction site, the components only need to be hoisted and welded. There is no water operation, no sand, and a large amount of dust generated during the whole process, which can reduce environmental pollution and impact nearby residents. However, the traditional concrete Buildings can’t do this, which means that steel structures have done a good job in environmental protection, the most important aspect of humanity. Besides, the recyclability of steel also conforms to the concept of sustainable development. In contrast to concrete buildings, after demolishing, there is a pile of construction waste.



3. Price
Steel structure saves construction costs and labor costs more than concrete. The cost of building a steel structure warehouse is 20%~30% lower than that of traditional concrete buildings, and steel structure is stronger and more durable than concrete and has the superior seismic performance.



4. Structural weight
The steel structure building itself has the characteristics of lightweight. The prefabricated steel structure warehouse walls and roof are made of light metal building materials, which are much lighter than the brick and concrete wall ceramic tile roof, which can reduce the warehouse’s overall weight and does not damage the stability of the structure.
